Specification
| Capacity | Machine Screw: M4 – M8 (5/32 – 5/16″) Standard Bolt: M5 – M16 (3/16 – 5/8″) High Strength Bolt: M5 – M14 (3/16 – 9/16″) Coarse Thread (in length): 22 – 125 mm (7/8″ – 4-7/8″) Wood (Auger Bit): 24 mm (15/16″) |
| Hex Shank | 6.35 mm (1/4″) |
| Impacts Per Minute (IPM) | Max: 0 – 3,800 | Hard: 0 – 3,600 Med.: 0 – 2,600 | Soft: 0 – 1,100 |
| Max Fastening Torque | 180 N·m (1,590 in. lbs.) |
| No Load Speed (RPM) | Max: 0 – 3,600 | Hard: 0 – 3,200 Med.: 0 – 2,100 | Soft: 0 – 1,100 |
| Dimensions (L x W x H) | 111 x 81 x 234 mm (4-3/8 x 3-3/16 x 9-1/4″) |
| Net Weight (with battery) | 1.5 kg (3.3 lbs) |
| Work Amount (approx.) | 970 pcs with BL1860B Coarse thread screw 65 mm at max impact mode |
| Standard Equipment Belt ClipAvailable Options RTJ: 1x Rapid Charger, 2x 5.0Ah Battery, 1x Makpac Connector Box Type 2 Z : Without Charger, Battery & Carrying Case |
|
* Items of standard equipment and specifications may vary by country or area. Net weight and dimensions may differ depending on the type of battery(ies) used. All pictures shown are for illustration purpose only. Continuous Usage Time/ Work Amount: Actual performance may vary based on application.
