Specification

Fastening Capacities	Standard Bolt: M8 – M16 (5/16″ – 5/8″) High Tensile Bolt: M6 – M12 (1/4″ – 1/2″)
Square Drive	12.7 mm (1/2″)
Impacts Per Minute (IPM)	0 – 3,200
No Load Speed (RPM)	0 – 2,600
Max Fastening Torque	145 N·m (107 ft.lbs.)
Dimensions (L x W x H)	168 x 66 x 205mm (6-5/8″ x 2-5/8″ x 8-1/8″)
Net Weight	1.1 – 1.2 kg (2.4 – 2.7 lbs.)
Standard equipment Belt ClipAvailable options SME: 1x Speed Charger, 2x 4.0Ah Battery WAE: 1x Standard Charger, 2x 2.0Ah Battery Z: Without Charger, Battery & Carrying Case

*Items of standard equipment and specifications may vary by country or area. Net weight and dimensions may differ depending on the type of battery(ies) used. All pictures shown are for illustration purpose only. Continuous Usage Time/ Work Amount: Actual performance may vary based on application.

Features

Delivers 145 N·m (107 ft.lbs.) of Max Torque in an Ultra Compact Size
Variable speed (0-2,600 RPM & 0-3,200 IPM) for a wide range of fastening applications
Ultra compact design at only 168 mm (6-5/8″) long and lightweight for reduced operator fatigue
Ideal for working in tight spaces and overhead applications
Built-in LED light with pre-glow and afterglow function illuminates the work area
Electric brake for increased operator safety
Same fastening torque in forward and reverse rotation
Reversing switch is conveniently located
Convenient 1/2″ (12.7 mm) square drive for quick socket changes
