Specification

Luminous Flux High: 3,000 | Mid: 1,700 | Low: 900 lm Illuminance at 1 m from the light source:
High: 1,250 lx | Med: 750 lx | Low: 400 lx
At 3 m from the light source:
High: 130 lx | Med: 80 lx | Low: 40 lx
At 5 m from the light source:
High: 50 lx | Med: 30 lx | Low: 15 lxLighting Coverage Front: 4.7 m | Sides: 5.6 m Dimensions (L x W x H) Folding Position:
260 x 216 x 1,000 mm (10-1/4 x 8-1/2 x 39-3/8″)
Operating Position (Max Height):
573 x 658 x 1,250 – 2,240 mm (22-1/2 x 26 x 49-1/4 x 88″)Net Weight 7.4 – 8.1 kg (16.3 – 17.9lbs.) Continuous Usage Time (approx.) Low: 10 hrs | Medium : 5.5 hrs | High: 3 hrs with BL1850B Standard Equipment
Shoulder Belt, Tool BagAvailable Option
Without Charger & Battery*Items of standard equipment and specifications may vary by country or area. Net weight and dimensions may differ depending on the type of battery(ies) used. All pictures shown are for illustration purpose only. Continuous Usage Time/ Work Amount: Actual performance may vary based on application.
